Nissan Pathfinder III facelift (2010-2014) atp-sw ets mtr mon r/cont 2 wait sw Wiring diagram
This page shows the only wiring diagram for the component.atp-sw ets mtr mon r/cont 2 wait sw, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram atp-sw ets mtr mon r/cont 2 wait sw (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 PPL
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 ON OFF
ATP IND
ATP-SW ETS MTR MON R/CONT 2 WAIT SW
AUTO IND VIGN
AUTO SW
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CPS LPS
DIODE 2 (BEHIND LEFT SIDE OF DASH)
ETS FAILL GND CAN-H CAN-L
FAIL IND
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE 18
HOT IN ON OR START FUSE 14
JOINT CONNECTOR
LOCK SW CPS
LT BLU WIRE
LT GRN WIRE
MEM B/U
OF ENGINE COMPT)
ORG/ WIRE
PNK CLPR SOL LOCK IND WIRE
PNK SENS GND IGN SW SSOF ETS WIRE
PNK WIRE
PPL
PPL MTR RLY ATP IND VIGN
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT
TRANSFER CASE CONTROL UNIT (NEAR LEFT KICK PANEL)
TRANSFER MOTOR (ON LEFT REAR OF TRANSFER CASE)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> 4wd circuit, all mode 4wd (1 of 2) -> ATP-SW ETS MTR MON R/CONT 2 WAIT SW
