Nissan Pathfinder III facelift (2010-2014) 16 17 20 13 11 12 14 out spd sens gnd out spd sens out spd sens pwr Wiring diagram

16 17 20 13 11 12 14 OUT SPD SENS GND OUT SPD SENS OUT SPD SENS PWR 4 7 2 8 VIGN REV RLY CAN-L START RLY 9 10 1 6 SUPPLY 1 SUPPLY 2 CAN-H K-LINE A/T ASSEMBLY A/T FLUID TEMPERATURE SENSOR ATF PRESSURE SWITCH 2 (LC/B) ATF SENS BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIRECT CLUTCH SOLENOID VALVE GND 2 GND-1 GRN WIRE GRY WIRE INPUT CLUTCH SOLENOID VALVE INPUT SPEED SENSOR 1 INPUT SPEED SENSOR 2 LINE PRESSURE SOLENOID VALVE LT GRN WIRE ORG/ WIRE OUTPUT SPEED SENSOR PNK WIRE PPL RED WIRE RED/BLK WIRE STARTING/ CHARGING SYSTEM TCM (TRANSMISSION CONTROL MODULE) TORQUE CONVERTER CLUTCH SOLENOID VALVE TRANSMISSION RANGE SWITCH WHT WIRE WHT/GRN WIRE YEL WIRE
