4wd circuit, part time mode 4wd for Nissan Pathfinder III (2004-2010)

ATP IND ATP IND SSOF ATP SWITCH (ON LEFT REAR OF TRANSFER CASE) ATP-SW BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (ON LOWER LEFT DASH PANEL) FAIL IND FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) GND MEM B/U GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE 21 HOT IN ON OR START FUSE 14 IGN SW IGNITION SWITCH IND LOCK LOCK IND LT BLU WIRE LT GRN WIRE MTR GND MTR MO 1 MTR MO 2 MTR RL 1 MTR RL 2 NEUTRAL ORG/ WIRE RED WIRE RUN WIRE SWITCH (ON FRONT OF TRANSFER CASE) TRANSFER CASE CONTROL UNIT (NEAR LEFT KICK PANEL) UNIFIED METER CONTROL UNIT VIGN VIGN VIO WIRE WAIT DETECTION SWITCH (ON LEFT FRONT OF TRANSFER CASE) WHT WIRE WHT/GRN WIRE YEL WIRE

ACTR SW 1 ACTR SW 2 ACTR SW 3 ACTR SW 4 BLK WIRE BLU WIRE BRN WIRE FUSE 57 FUSE 58 FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) FUSE, RELAY BOX (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK J GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE ORG/ WIRE RED WIRE SHIFT SWITCH TRANSFER SHIFT LOW RELAY (IN FUSE, RELAY BOX) TRANSFER SHUT OFF RELAY 1 TRANSFER SHUT OFF RELAY 2 VIO WIRE WHT WIRE WHT/GRN WIRE YEL WIRE
