Car Wiring Diagrams for Base radio circuit for Nissan Pathfinder III (2004-2010)

AUDIO UNIT BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE FR SP LH (+) FR SP LH (-) RR SP LH (+) RR SP LH (-) FR SP RH (+) FR SP RH (-) RR SP RH (+) RR SP RH (-) FUSE 29 FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE 4 ILL CONT OUT TAIL/ILL RLY LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR SPEAKER LT GRN WIRE ORG/ WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR SPEAKER WHT WIRE WHT/BLK WIRE YEL WIRE
