Nissan Pathfinder III (2004-2010) comp in shield Wiring diagrams

This page contains all the electrical diagrams for the component. comp in shield, in which he is found in the car Nissan Pathfinder III (2004-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram comp in shield (1 of 4)

Wiring diagram comp in shield for Nissan Pathfinder III (2004-2010) (1 of 4)

Get lifetime access to Nissan Pathfinder III (2004-2010)

ANT AMP ANT AMP ANTENNA AMPLIFIER AUDIO-BUS-LH+ AUDIO-BUS-RH+ SHIELD HP-LH- HP-RH- AUDIO-BUS-LH- AUDIO-BUS-RH- AUX AUDIO LH+ AUX AUDIO RH+ AUX GND AUX IN JACK AV CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE CD-DVD-EJECT SHIELD AUX-AUDIO-LH+ AUX-GND COMBINATION SWITCH (SPIRAL CABLE) COMP IN SHIELD COMP IN SYNC DISP IT DISPLAY UNIT FUSE 29 BOX (RIGHT REAR OF ENGINE COMPT) FUSE, FUSIBLE LINK GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES IT DISP LEFT WINDOW ANTENNA GRID LT BLU WIRE LT GRN WIRE NCA WIRE PPL RED WIRE RED/BLK WIRE RGB GND RGB SYNC RGB SYNC GND RGB-GND RGB-SYNC RGB-SYNC-GND YS HP VP IT_DISP DISP_IT SHIELD RIGHT WINDOW ANTENNA GRID SEEK VOL MODE DOWN DOWN STEERING WHEEL AUDIO CONTROL SWITCHES SHIELD SHIELD FR-RH-PRE+ FR-RH-PRE- RR-RH-PRE+ RR-RH-PRE- STRG-SW-GND STRG-SW-B VOL UP UP VR SEEK WHT WIRE YEL WIRE

Go to component -> Bose radio circuit, with navigation (1 of 4) -> COMP IN SHIELD

Wiring diagram comp in shield (2 of 4)

Wiring diagram comp in shield for Nissan Pathfinder III (2004-2010) (2 of 4)

Get lifetime access to Nissan Pathfinder III (2004-2010)

BLK WIRE BRN WIRE COMP IN COMP IN SHIELD COMP SYNC DISP IT DISPLAY UNIT FUSE 12 FUSE 17 FUSE 4 FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) GRN WIRE GRN/BLK WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR ACC INV GND INV VCC IT DISP LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PPL RED WIRE RED/BLK WIRE RGB GND RGB SYNC RGB SYNC GND SHIELD SIG VCC SUG GND WHT WIRE WHT/GRN WIRE YEL WIRE

Go to component -> Bose radio circuit, without navigation (2 of 4) -> COMP IN SHIELD

Wiring diagram comp in shield (3 of 4)

Wiring diagram comp in shield for Nissan Pathfinder III (2004-2010) (3 of 4)

Get lifetime access to Nissan Pathfinder III (2004-2010)

ANTEENA BACKUP BLK WIRE BLU WIRE BRN WIRE CAMERA COMP IN COMP IN SHIELD COMP SYNC DATA EARTH DISP IT DISPLAY UNIT EARTH FUSE 12 FUSE 17 FUSE 4 FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) GRN WIRE GRN/BLK WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR ACC INV GND INV VCC IT DISP LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK 28 29 WIRE PNK WIRE PPL REAR VIEW CAMERA (CENTER OF BACK DOOR) RED WIRE RED/BLK WIRE REQ+ RGB GND RGB SYNC RGB SYNC GND SAT LCH (+) SAT RCH (-) SATELLITE ANTENNA SATELLITE RADIO TUNER/PRE-WIRING FOR SATELLITE RADIO TUNER (IF EQUIPPED) SHIELD SIG GND SIG VCC WHT WIRE WHT/GRN WIRE YEL WIRE

Go to component -> Mid-line radio circuit (2 of 3) -> COMP IN SHIELD
