Nissan Pathfinder II (1995-2004) Anti-theft circuit

49 59 64 BAT H/L OUT 2 GND BLK WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE FUSE 10 FUSE 11 FUSE 24 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GLASS HATCH SWITCH GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HEADLIGHTS SYSTEM HOOD SWITCH HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN COM ANTI-THEFT IND HORN OUT GND IMMOBILIZER SYSTEM LEFT FRONT DOOR SWITCH BACK DOOR SWITCH LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE PPL/RED WIRE PPL/WHT WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR DOOR SWITCH SWITCH SECURITY INDICATOR LAMP SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK) WHT/BLK WIRE WHT/PPL WIRE WIPER/ WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

BACK DOOR BACK DOOR KEY CYLINDER SWITCH BLK WIRE BLU WIRE BRN WIRE COM I/F COMMUNICATIONS I/F FRONT POWER WINDOW MAIN SWITCH (DOOR LOCK, UNLOCK SWITCH) GLASS HATCH GRN/BLK WIRE LEFT FRONT DOOR KEY CYLINDER SWITCH LOCK UNLOCK LOCK-BETWEEN FULL STROKE, NORMAL UNLOCK-BETWEEN FULL STROKE, NORMAL LT GRN WIRE RIGHT FRONT POWER WINDOW SWITCH (DOOR LOCK, UNLOCK SWITCH) UNLK YEL WIRE
