Car Wiring Diagrams for Manual a/c circuit for Nissan Pathfinder II (1995-2004)

A/C RELAY (IN RELAY BOX 1) A/C SWITCH ACRLY ARCON AVCC BLK WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMPRESSOR) DIODE (BEHIND RIGHT SIDE OF DASH) ENGINE CONTROL MODULE (ECM) (BEHIND CENTER OF DASH) FAN SWITCH FRE FRE REC FUSE 1 FUSE 11 FUSE 2 FUSE 6 FUSE BLOCK (J/B) (BEHIND DASH, LEFT OF STEERING COLUMN) GND A GRN WIRE GRN/RED WIRE GRN/WHT WIRE HOT IN ON HOT IN ON OR START INTAKE DOOR MOTOR (BEHIND GLOVE BOX, ON HEATER INTAKE UNIT) LT GRN WIRE LT GRN/RED WIRE MODE SWITCH NCA WIRE OFF PDPRES PNK/BLK WIRE REC RECIRCULATION SWITCH RED WIRE REFRIGERANT PRESSURE SENSOR (ON A/C LIQUID TANK) WHT WIRE WHT/PPL WIRE YEL/BLK WIRE
