Nissan Pathfinder II (1995-2004) up auto up auto dn dn Wiring diagram
This page shows the only wiring diagram for the component.up auto up auto dn dn, which is found in the car Nissan Pathfinder II (1995-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up auto up auto dn dn (1 of 1)
49 64 BATTERY (FUSE)
AUTO DN
AUTO UP
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CIRCUIT BREAKER (ON TOP OF FUSE BLOCK)
DIODE
DOOR LOCKS SYSTEM
DOOR SW (AS)
DOOR SW (DR)
ENCODER
FRONT LEFT -
FRONT POWER WINDOW MAIN SWITCH
FRONT RIGHT -
FUSE
FUSE BLOCK (BEHIND DASH,
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION COM RAP
ILLUM
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER WINDOW REGULATOR
LEFT REAR POWER WINDOW REGULATOR
LEFT REAR POWER WINDOW SUB-SWITCH DN UP DN UP
LOCK
LT GRN WIRE
POWER WINDOW RELAY (ON TOP OF FUSE BLOCK)
REAR LEFT -
REAR RIGHT -
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER WINDOW REGULATOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW REGULATOR
RIGHT REAR POWER WINDOW SUB-SWITCH DN UP UP
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK)
UP AUTO UP AUTO DN DN
UP AUTO UP UNLOCK
UP DN
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power window circuit -> UP AUTO UP AUTO DN DN
