Nissan Pathfinder II (1995-2004) rxd txd req 10 9 8 7 6 5 4 3 Wiring diagram
This page shows the only wiring diagram for the component.rxd txd req 10 9 8 7 6 5 4 3, which is found in the car Nissan Pathfinder II (1995-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rxd txd req 10 9 8 7 6 5 4 3 (1 of 1)
1 2 3 4 5 SEEK/APS UP GND PWR MODE
1 2 3 HORN RLY DATA OUT GND
1 2 3 RR LH (-) OUT RR LH (+) OUT
2 1 LH (+) OUT LH (-) OUT
26 27 28 29 PWR ON SIG SEEK/APS UP
42 41 CD LH IN (+) CD LH IN (-)
7 8 PULSE
ANTENNA IN
AUDIO AMPLIFIER RELAY (BEHIND LEFT LUGGAGE COMPT TRIM)
AUDIO UNIT
AUX BOX (LEFT "C" PILLAR)
BATTERY
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
CD AUTO CHANGER
DATA GND GND CD RH IN (+) CD RH IN (-)
FUSE 10
FUSE 4
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GND ILLUM ILLUM BACK UP
GRN/ WHT WIRE
GRN/WHT WIRE
GROUND GROUND RR RH (+) OUT RR RH (-) OUT
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT FRONT DOOR SPEAKER 4 5
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
LT GRN/RED WIRE
MODE
NCA WIRE
ORG/ WIRE
PNK PPL WIRE
PNK RR LH (+) IN WIRE
PNK WIRE
PNK/BLK WIRE
PNK/GRN WIRE
POWER ANTENNA SYSTEM
PPL
PPL RR RH (-) IN
REAR SPEAKER AMPLIFIER (BEHIIND LEFT LUGGAGE COMPT TRIM)
REAR TV SWITCH
RED GRN/ WIRE
RED WIRE
RED/GRN WIRE
REMOTE ON/OFF
RH (+) OUT RH (-) OUT PPL
RIGHT FRONT DOOR SPEAKER 4 5
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
ROD ANTENNA
RR LH IN-
RR RH IN-
RX TX REQ
RXD TXD REQ 10 9 8 7 6 5 4 3
SPIRAL CABLE
STEERING WHEEL RECEIVER CONTROL SWITCH
STEERING WHEEL SWITCH (AUDIO)
WHT WIRE
WINDOW ANTENNA
YEL WIRE
Go to component -> Radio circuits, bose -> RXD TXD REQ 10 9 8 7 6 5 4 3
