Nissan Pathfinder II (1995-2004) p range sw Wiring diagram
This page shows the only wiring diagram for the component.p range sw, which is found in the car Nissan Pathfinder II (1995-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p range sw (1 of 1)
A/T DEVICE (AT BASE OF SELECTOR LEVER)
BLK WIRE
BRN WIRE
DIODE (RIGHT KICK PANEL)
FUSE 11
FUSE 14
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
LT GRN WIRE
NCA WIRE
P RANGE SW
PARK POSITION SWITCH
RED WIRE
RED/BLK WIRE
RELAY
SHIFT LOCK SOLENOID
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
W/ MEMORY SEAT
W/O MEMORY SEAT
WHT WIRE
YEL WIRE
