Nissan Pathfinder II (1995-2004) left parking lamp right parking lamp Wiring diagram

1 2 3 GND OUTPUT POWER 49 57 58 64 BAT (FUSE) A/L SW ANTI-LOCK BRAKES SYSTEM AUTO LIGHT SENSOR BACK DOOR SWITCH BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE COMBINATION SWITCH (LIGHTING SWITCH) CRUISE CONTROL SYSTEM FLASHER LH OUT FLASHER RH OUT FUSE 10 FUSE 11 FUSE 24 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX FUSE 61 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HIGH MOUNTED STOPLAMP HOT AT ALL TIMES HOT IN ACCY OR ON HOT IN ON OR START IGN LEFT FRONT DOOR SWITCH LEFT PARKING LAMP RIGHT PARKING LAMP LEFT REAR COMBINATION LAMP LEFT REAR DOOR SWITCH OFF AUTO PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR COMBINATION LAMP RIGHT REAR DOOR SWITCH SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK) STOP STOP TAIL TAIL TAIL LAMP RELAY (IN RELAY BOX 1) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE
