Nissan Pathfinder II (1995-2004) brk sw vsp in fld temp gnd Wiring diagram

25 86 82 70 TACHO VSP A/T DEVICE (OVERDRIVE CONTROL SWITCH) (BASE OF SELECTOR LEVER) A/T FLUID TEMP IND A/T FLUID TEMP SENSOR OVER- SHIFT SOL VALVE A/T FLUID TEMP SWITCH ASCD CONTROL UNIT (BEHIND LEFT KICK PANEL) ASCD GND 1-SW 2-SW MEM B/U AUTOMATIC TRANSAXLE BLK WIRE BLK/PNK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRK SW VSP IN FLD TEMP GND BRN/YEL WIRE CIRCUIT CLOSED THROTTLE 3 1 CLUTCH SOL COMBINATION METER DATA IN DATA OUT SENS PWR LAN D-SW R-SW P/N-SW DATA LINK CONNECTOR (ON LOWER DASH PANEL, LEFT OF STEERING COLUMN) DIODE (BEHIND LEFT SIDE OF DASH) DROPPING RESISTOR (RIGHT SIDE OF ENGINE COMPT, NEAR BATTERY) ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE, ON WATER OUTLET) FUSE 14 FUSE 16 FUSE 18 FUSE 24 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GND-A AVCC LAN IDLE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START IDLE FULL SW ASCD V IGN OV R/C J/C (BEHIND LEFT SIDE OF DASH) LINE PRESS SOL VALVE LT GRN/RED WIRE NCA WIRE O/D OFF IND OD SW ORG/BLK WIRE ORG/BLU WIRE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE REAR REVOLUTION SENSOR RED WIRE RED/BLK WIRE RED/YEL WIRE RUN WIRE SHIFT SOL VALVE TCC SOL VALVE STARTING SYSTEM STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TRANSMISSION ADAPTER CASE TRANSMISSION CONTROL MODULE (BEHIND DASH, LEFT OF STEERING COLUMN) TRANSMISSION EXTENSION ASSEMBLY TSS TACHO VSP-2 TH SENS SENS GND TURBINE REVOLUTION SENSOR (TOP FRONT OF TRANS- MISSION CASE) UNIFIED METER CONTROL UNIT V IGN SHIFT A SHIFT B O/D IND VEHICLE SPEED SENSOR (TOP OF TRANS- MISSION) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WOT YEL WIRE YEL/BLK WIRE
