Nissan Note E12 (2012-2016) w/o around view monitor Wiring diagrams
This page contains all the electrical diagrams for the component. w/o around view monitor, in which he is found in the car Nissan Note E12 (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/o around view monitor wiring diagram (1 of 2)
AROUND VIEW MONITOR CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
AUDIO UNIT
AV CONTROL UNIT
BACKUP LAMP
BLK WIRE
CVT
FUSE 49 POWER DISTRIBUTION MODULE ENGINE ROOM) (LEFT REAR OF ENGINE COMPT)
GRY WIRE
HOT IN ON OR START
HOT IN ON OR START FUSE BLOCK (J/B) FUSE 3 (UNDER LEFT END OF DASH)
IPDM E/R (INTELLIGENT
LEFT REAR COMBINATION LAMP
LT BLU WIRE
M/T
ORG/ WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (BACKUP) (ON LEFT SIDE OF TRANSAXLE)
RED WIRE
RED/WHT WIRE
REVERSE
RIGHT REAR COMBINATION LAMP
TRANSMISSION RANGE SWITCH (LEFT REAR SIDE OF TRANSAXLE)
W/O AROUND VIEW MONITOR
YEL WIRE
YEL/BLU WIRE
Go to component -> Backup lamps circuit -> W/O AROUND VIEW MONITOR
w/o around view monitor wiring diagram (2 of 2)
"D" PILLAR) (W/ AROUND VIEW MONITOR: BEHIND RIGHT REAR QUARTERPANEL)
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 37
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT COMBINATION LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
PARKING
PNK WIRE
PPL
PPL 1 2
RED WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
STOP
TAIL
TAIL LAMP RELAY
TURN
W/O AROUND VIEW MONITOR
WHT WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> W/O AROUND VIEW MONITOR
