Nissan Note E12 (2012-2016) shield sv-1 video gnd sv-1 video sig fv-power gnd Wiring diagrams
This page contains all the electrical diagrams for the component. shield sv-1 video gnd sv-1 video sig fv-power gnd, in which he is found in the car Nissan Note E12 (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shield sv-1 video gnd sv-1 video sig fv-power gnd (1 of 2)
AROUND VIEW MONITOR CONTROL UNIT (UNDER FRONT
BLK WIRE
BLU WIRE
BRN WIRE
CAN-H
COMPUTER DATA LINES SYSTEM
FRONT CAMERA
GRN WIRE
IGN
LEFT DOOR MIRROR
LT BLU WIRE
LT GRN WIRE
PASSENGER'S SEAT)
PNK CAN-L WIRE
PPL
REAR VIEW CAMERA (LEFT SIDE OF BACK DOOR)
RED WIRE
REVERSE
RIGHT DOOR MIRROR
RV-VIDEO GND RV-VIDEO SIG
SHIELD
SHIELD (OR SHIELD)
SHIELD FV-VIDEO GND FV-VIDEO SIG
SHIELD SV-1 VIDEO GND SV-1 VIDEO SIG FV-POWER GND
SHIELD SV-2 VIDEO GND SV-2 VIDEO SIG
VIDEO O/P GND VIDEO O/P SIG RV-POWER GND (OR SHIELD)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Navigation circuit (3 of 3) -> SHIELD SV-1 VIDEO GND SV-1 VIDEO SIG FV-POWER GND
