Nissan Note E12 (2012-2016) sedan hatchback cvt cvt, a/t Wiring diagram
This page shows the only wiring diagram for the component.sedan hatchback cvt cvt, a/t, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sedan hatchback cvt cvt, a/t (1 of 1)
A/T, M/T CVT
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CHARGING CIRCUIT
CLUTCH INTERLOCK SWITCH (M/T) (ON CLUTCH PEDAL BRACKET) HATCHBACK CVT, A/T
COMPUTER DATA LINES SYSTEM
FUSE
FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK A
FUSIBLE LINK BOX
FUSIBLE LINK D
FUSIBLE LINK H
GRN WIRE
HOT W/ IGNITION RELAY 1 ENERGIZED
IGNITION SWITCH
LT GRN WIRE
NCA WIRE
OFF
PNK WIRE
RED WIRE
SEDAN CVT
SEDAN HATCHBACK CVT CVT, A/T
STARTER CONTROL RELAY
STARTER MOTOR
TRANSMISSION RANGE SWITCH (LEFT REAR SIDE OF TRANSAXLE)
WHT WIRE
Go to component -> Starting circuit, without intelligent key -> SEDAN HATCHBACK CVT CVT, A/T
