Nissan Note E12 (2012-2016) sedan early production, hatchback Wiring diagram
This page shows the only wiring diagram for the component.sedan early production, hatchback, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sedan early production, hatchback (1 of 1)
5 6 PNK WIRE
A/T
ACTIVE GRILLE SHUTTER RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CVT
CVT A/T
ENGINE COMPT)
FM GND
FUEL LEVEL SENSOR
FUEL LEVEL SENSOR UNIT, FUEL PUMP (TOP OF FUEL TANK) FUEL PUMP
FUEL TANK TEMPERATURE SENSOR
FUSE 27
FUSE 3
FUSE 49
FUSE 54
FUSE 8
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT REAR OF
GND POWER
GND(ILL)
GRN WIRE
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN
INSTRUMENT CLUSTER SYSTEM
M/T
MALFUNCTION INDICATOR LAMP (MIL)
OTHERS
PARK/ NEUTRAL POSITION SWITCH (M/T) (ON LEFT SIDE OF TRANSAXLE)
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
SEDAN
SEDAN EARLY PRODUCTION, HATCHBACK
SEDAN LATE PRODUCTION
TRANSMISSION RANGE SWITCH (LEFT REAR SIDE OF TRANSAXLE)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l (4 of 5) -> SEDAN EARLY PRODUCTION, HATCHBACK
