Nissan Note E12 (2012-2016) rr wiper auto stop sw rear wiper mtr 44 54 56 68 Wiring diagram
This page shows the only wiring diagram for the component.rr wiper auto stop sw rear wiper mtr 44 54 56 68, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr wiper auto stop sw rear wiper mtr 44 54 56 68 (1 of 1)
55 50 42 GND BATT (F/L) BATT FUSE
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMBINATION SWITCH (WIPER, WASHER SWITCH)
FRONT, REAR WASHER MOTOR (IN WASHER FLUID RESERVOIR)
FUSE 12
FUSE 6
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PPL PNK WIRE
REAR WIPER MOTOR (CENTER OF BACK DOOR)
RED WIRE
RR WIPER AUTO STOP SW REAR WIPER MTR 44 54 56 68
W/ INTELLIGENT KEY SYSTEM W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> RR WIPER AUTO STOP SW REAR WIPER MTR 44 54 56 68
