Nissan Note E12 (2012-2016) lh buckle sw Wiring diagram
This page shows the only wiring diagram for the component.lh buckle sw, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh buckle sw (1 of 1)
1 24 6 7 5 3 4 8 9 18 IGN SEAT BELT REMIND
2 25 23 19 22 51 54 53 52 GND TELL TALE LP-A AIR BAG W/L
59 60 CAN-H CAN-L PNK WIRE
AIR BAG DIAGNOSIS SENSOR UNIT (UNDER CENTER FLOOR CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 3
FUSE 7
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
GND RH SATELLITE (+) LH SATELLITE (-) LH SATELLITE (+) RH SATELLITE (-)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT IN ON OR START
LEFT FRONT SIDE AIR BAG SATELLITE SENSOR (BASE OF LEFT "B" PILLAR)
LEFT REAR SIDE AIR BAG SATELLITE SENSOR (LEFT REAR SIDE "C" PILLAR)
LEFT SIDE CURTAIN AIR BAG MODULE (IN ROOF RAIL ABOVE LEFT REAR DOOR)
LH BUCKLE SW
LH SENS (+) GND RR SAT SENS LH (+) RR STA SENS LH (-) SHIELD
LH SENS (-) PPL
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK SHIELD 10 11 12 13 14 WIRE
PNK WIRE
PPL
PPL PNK SHIELD PNK WIRE
RED WIRE
RH SENS +
RIGHT FRONT DOOR SATELLITE SENSOR (IN RIGHT FRONT DOOR)
RIGHT FRONT SEAT BELT PRE-TENSIONER (BASE OF RIGHT "B"PILLAR)
RIGHT FRONT SIDE AIR BAG MODULE (OUTER EDGE OF RIGHT FRONT SEAT BACK)
RIGHT FRONT SIDE AIR BAG SATELLITE SENSOR (BASE OF RIGHT "B" PILLAR)
RIGHT REAR SIDE AIR BAG SATELLITE SENSOR (RIGHT REAR SIDE "C" PILLAR)
RIGHT SIDE CURTAIN AIR BAG MODULE (IN ROOF RAIL ABOVE RIGHT REAR DOOR)
S-RH (-)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> LH BUCKLE SW
