Nissan Note E12 (2012-2016) key les turn pwr sup ppl key les, auto sens gnd Wiring diagram
This page shows the only wiring diagram for the component.key les turn pwr sup ppl key les, auto sens gnd, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key les turn pwr sup ppl key les, auto sens gnd (1 of 1)
38 37 39 40 36 35 34 33 32 6 5 4 3 2 IGN SW KEY SW CAN-H CAN-L
BELT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BRAKE IND
BRN WIRE
BUCKLE ASSEMBLY)
BUZZER
CAN L
CAN-H
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DOOR SW (DR)
FUSE
FUSE 12
FUSE 2
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK G
GND PWR
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
KEY LES TURN PWR SUP KEY LES TURN SIG 50 42 55 BAT (F/L) BAT (FUSE) GND (PWR)
KEY LES TURN PWR SUP PPL KEY LES, AUTO SENS GND
KEY LES TURN SIG
KEY SWITCH
LEFT FRONT DOOR SWITCH (LEFT FRONT ``B" PILLAR)
LEFT SEAT BELT BUCKLE SWITCH (IN LEFT FRONT SEAT BELT
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY)
PNK PPL WIRE
PNK WIRE
PPL
PPL KEY LES, AUTO SENS GND
PPL PNK WIRE
RED WIRE
RED/WHT WIRE
REMOTE KEYLESS ENTRY RECEIVER (UNDER CENTER CONSOLE)
SEAT BELT IND
TIRE PRESSURE IND
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Warning systems circuit, without intelligent key -> KEY LES TURN PWR SUP PPL KEY LES, AUTO SENS GND
