Nissan Note E12 (2012-2016) hazard switch door mirror remote control switch Wiring diagram
This page shows the only wiring diagram for the component.hazard switch door mirror remote control switch, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard switch door mirror remote control switch (1 of 1)
ASCD STEERING SWITCH (IF EQUIPPED)
AUDIO ILL+ UNIT
AV ILL+ CONTROL UNIT
BLK WIRE
BLU WIRE
CAN-H CAN-L SIG
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER (LEFT REAR DATA LINES OF ENGINE SYSTEM COMPT)
CVT SHIFT SELECTOR (IF EQUIPPED)
DIODE (W/ INTELLIGENT KEY) (BEHIND CENTER OF DASH)
FRONT AIR CONTROL
FUSE 37
GND SIG
GRN WIRE
GRY WIRE
HAZARD SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (LEFT REAR
LEFT HEATED SEAT SWITCH
LT BLU WIRE
LT GRN WIRE
OF ENGINE COMPT)
ORG/ WIRE
PNK WIRE
PUSH BUTTON IGNITION SWITCH
RED WIRE
RIGHT HEATED SEAT SWITCH
STEERING WHEEL AUDIO CONTROL SWITCHES (IF EQUIPPED)
TAIL LAMP RELAY
TAIL/L IGN RLY
VDC OFF SWITCH
W/ DISPLAY AUDIO W/ BASE AUDIO
W/ INTELLIGENT KEY
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> HAZARD SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
