Nissan Note E12 (2012-2016) fuse 48 cpu fuse fuse 50 fuel pump relay push Wiring diagram
This page shows the only wiring diagram for the component.fuse 48 cpu fuse fuse 50 fuel pump relay push, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 48 cpu fuse fuse 50 fuel pump relay push (1 of 1)
ACCESSORY RELAY 1
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM ENGINE CONTROLS SYSTEM TRANSMISSIONS SYSTEM
ANTI-THEFT SYSTEM
ANTI-THEFT, BODY COMPUTER, DEFOGGER SYSTEMS
BLK WIRE
BLOWER RELAY
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN CAN STRT SW
CONSOLE POWER SOCKET
DEFOGGER SYSTEM
ECM RELAY
ENGINE AIR CONTROLS CONDITIONING, SYSTEM COOLING FANS SYSTEMS
ENGINE CONTROLS SYSTEM
FROM ACCESSORY RELAY 2 (DIAGRAM 3 OF 3)
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 3 OF 3)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 3)
FROM IGNITION RELAY 2 (DIAGRAM 3 OF 3)
FUSE 11
FUSE 12
FUSE 15 FUSE 17
FUSE 2 FUSE 7
FUSE 22 FUSE 21 FUSE 20
FUSE 3 FUSE 6
FUSE 48 CPU FUSE FUSE 50 FUEL PUMP RELAY PUSH
FUSE 5
FUSE 52
FUSE 53
FUSE 55
FUSE 8
FUSE 9
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE FUSE 54
GRN WIRE
GRY WIRE
IGNITION RELAY 1
IGNITION SWITCH (W/O INTELLI- GENT KEY
LT BLU WIRE
LT GRN WIRE
MIRRORS, NAVIGATION, SOUND SYSTEMS
MTR CPU
OFF
OFF ON
ORG/ WIRE
PNK PNK WIRE
PNK TO FUSE BLOCK (J/B) (DIAGRAM 3 OF 3) WIRE
PNK WIRE
RED WIRE
RELAY
STARTER CONTROL
STARTING/ CHARGING SYSTEM
STARTING/ CHARGING, TRANSMISSIONS SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
SYSTEM
THROTTLE CONTROL MOTOR RELAY
TO FRONT WIPER RELAY (DIAGRAM 1 OF 3)
TO FUSE 10 (DIAGRAM 3 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 3 OF 3) FROM BCM (DIAGRAM 3 OF 3)
W/ HEATED SEATS
W/ INTELLIGENT KEY SYSTEM
W/O HEATED SEATS
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> FUSE 48 CPU FUSE FUSE 50 FUEL PUMP RELAY PUSH
