Nissan Note E12 (2012-2016) exterior lights system defogger system Wiring diagram
This page shows the only wiring diagram for the component.exterior lights system defogger system, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior lights system defogger system (1 of 1)
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BATTERY (F/L)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM
FUSE 12
FUSE 18
FUSE 2
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE, FUSIBLE
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
INTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM INTERIOR LIGHTS SYSTEM
LINK BOX (LEFT REAR OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
LUGGAGE LAMP OUTPUT
ORG/ WIRE
PNK DOOR SW (BACK) FLASH OUTPUT (RIGHT) FLASH OUTPUT (LEFT) WIRE
PNK WIRE
POWER WINDOWS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS
PPL
PWR WINDOW PWR SPLY (RAP) DOOR UNLOCK OUTPUT (AS, RR, RL) DOOR LOCK OUTPUT GND
REAR WIPER AUTO STOP SW
RED WIRE
RED/YEL WIRE
WHT WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER, HEADLIGHTS, EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS
YEL WIRE
Go to component -> Body control modules circuit, without intelligent key -> EXTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM
