Nissan Note E12 (2012-2016) clutch sw ign sw ascd strg sw snsr gnd Wiring diagram

5 6 PNK WIRE ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) ACTIVE GRILLE SHUTTER (BEHIND LEFT END OF FRONT GRILLE) APP SNSR 1 SNSR GND BLK WIRE BLOCK BLU WIRE BLU/YEL WIRE BRN WIRE CLUTCH PEDAL POSITION SWITCH (M/T) (ON CLUTCH PEDAL BRACKET) CLUTCH SW IGN SW ASCD STRG SW SNSR GND COMPUTER DATA LINES SYSTEM CRANKSHAFT POSITION SENSOR (POS) (RIGHT REAR OF CYLINDER HEAD) CRUISE CONTROL SYSTEM CVT A/T DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DLC ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT) ECM GND ENGINE OIL PRESSURE SENSOR (LOWER LEFT SIDE OF ENGINE) FUSE 30 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES INTAKE CAMSHAFT POSITION SENSOR (LEFT REAR SIDE OF CYLINDER HEAD) LT BLU WIRE LT GRN WIRE M/T ORG/ WIRE PNK CAN-L CAN-H REF PRESS SNSR WIRE PNK WIRE POS SNSR PPL RED WIRE RED/WHT WIRE REFRIGERANT PRESSURE SENSOR (ON A/C LIQUID TANK) SEDAN SENSOR 1 SENSOR 2 SNSR PWR SPLY STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) WHT WIRE YEL WIRE
