Nissan Note E12 (2012-2016) blwr mtr rly output Wiring diagram
This page shows the only wiring diagram for the component.blwr mtr rly output, which is found in the car Nissan Note E12 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blwr mtr rly output (1 of 1)
ACC/ ON
ACCESSORY RELAY 2 (IN RELAY HOLDER ABOVE FUSE BLOCK (J/B))
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BLWR MTR RLY OUTPUT
BRN WIRE
COOLING FANS, AIR CONDITIONING SYSTEMS
DOOR LOCKS, ANTI-THEFT, WARNING SYSTEMS
ELECTRONIC POWER STEERING SYSTEM
ENG STRT SW
ENGINE CONTROLS SYSTEM
FROM BLOWER RELAY (DIAGRAM 2 OF 3)
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 2 OF 3)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUSE 10
FUSE 18
FUSE 24
FUSE 29 FUSIBLE LINK F FUSE
FUSE 30
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE/ FUSIBLE LINK, RELAY BOX (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK G FUSE
FUSIBLE LINK H FUSE 28
FUSIBLE LINK J FUSE 27
FUSIBLE LINK M FUSIBLE LINK I
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
IGN RLY OUTPUT 2
IGNITION RELAY 2
ILL
INSTRUMENT CLUSTER, SOUND, NAVIGATION, BODY COMPUTER SYSTEMS
LT BLU WIRE
LT GRN WIRE
NAVIGATION, SOUND SYSTEMS
ORG/ WIRE
PNK WIRE
PPL
PPL PWR POSITION LED
PUSH BUTTON IGNITION SWITCH (W/ INTELLIGENT KEY SYSTEM)
PUSH SWITCH
RED WIRE
RLY OUTPUT
SEATS SYSTEM
STARTING/ CHARGING, HORNS SYSTEMS
TO FUSE 2 (DIAGRAM 2 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TRANSMISSIONS SYSTEM
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> BLWR MTR RLY OUTPUT
