Nissan Note E12 (2012-2016) blu Wiring diagrams
This page contains all the electrical diagrams for the component. blu, in which he is found in the car Nissan Note E12 (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram blu (11 of 69)
1 2 3 4 5 6 RR DEF RLY O/P INPUT 5 INPUT 4 INPUT 3 INPUT 2 INPUT 1
56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 BAT SAVER O/P BAT (FUSE)
7 8 9 KEY CYL UNLOCK SW KEY CYL LOCK SW BRK SW 1
A/C IND OUT
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM
BAT (F/L)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CENTRAL DOOR LOCK SW CENTRAL DOOR UNLOCK SW
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DONGLE UNIT (CANADA) (BEHIND LEFT
DOOR LOCK OUTPUT DOOR UNLOCK COMMON GND PWR WIND PWR SUPPLY (IGN)
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM WIPER/WASHER SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS SYSTEM
DOOR LOCKS, ANTI-THEFT, WARNING SYSTEMS
DOOR LOCKS, INTERIOR LIGHTS SYSTEMS
DOOR UNLOCK OUTPUT LH FLASHER OUTPUT RH FLASHER OUTPUT PPL
DR LK STUS SW (DR) OUTPUT 5 OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 PNK PPL WIRE
DRIVER REQUEST SW ENGINE START SW
FUSE
FUSE (UNDER LEFT END OF DASH)
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM POWER DISTRIBUTION SYSTEM INTERIOR LIGHTS SYSTEM
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM DOOR LOCKS SYSTEM
PPL
PUSH SWITCH (BEHIND CENTER PUSH BUTTON OF DASH) IGNITION SWITCH
REAR DEFOGGER SW
REAR WIPE MTR OUT RR, RL DOOR UNLOCK OUT
RED WIRE
RED/YEL WIRE
ROOM LAMP OUTPUT
SHIFT POS, PRK POS SW INTELLIGENT TUNER CAN-H CAN-L
STARTING/CHARGING SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM DOOR LOCKS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit, with intelligent key -> BLU WIRE
Wiring diagram blu (12 of 69)
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BATTERY (F/L)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM
FUSE 12
FUSE 18
FUSE 2
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE, FUSIBLE
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
INTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM INTERIOR LIGHTS SYSTEM
LINK BOX (LEFT REAR OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
LUGGAGE LAMP OUTPUT
ORG/ WIRE
PNK DOOR SW (BACK) FLASH OUTPUT (RIGHT) FLASH OUTPUT (LEFT) WIRE
PNK WIRE
POWER WINDOWS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS
PPL
PWR WINDOW PWR SPLY (RAP) DOOR UNLOCK OUTPUT (AS, RR, RL) DOOR LOCK OUTPUT GND
REAR WIPER AUTO STOP SW
RED WIRE
RED/YEL WIRE
WHT WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER, HEADLIGHTS, EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS
YEL WIRE
Go to component -> Body control modules circuit, without intelligent key -> BLU WIRE
Wiring diagram blu (13 of 69)
1 2 PNK CAN-L CAN-H WIRE
10 11 PNK CAN-L CAN-H WIRE
17 8 PNK CAN-L CAN-H WIRE
2 1 PNK WIRE
2 5 PNK CAN-L CAN-H WIRE
23 33 CAN-L CAN-H
40 39 40 39 PNK CAN-L CAN-H WIRE
60 59 PNK CAN-L CAN-H WIRE
61 62 PNK CAN-L CAN-H WIRE
88 83 84 K-LINE CAN-L CAN-H PNK WIRE
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (RIGHT REAR OF ENGINE COMPT)
ABS/TCS/VDC CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT (UNDER CENTER FLOOR CONSOLE)
AROUND VIEW MONITOR CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
AV CONTROL UNIT (W/ NAVIGATION)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
CAN L
CAN-H
CAN-L CAN-H
COMBINATION METER
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DISTRIBUTION MODULE ENGINE ROOM) (LEFT REAR OF ENGINE COMPT)
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
END OF DASH)
EPS CONTROL UNIT (ON STEERING COLUMN)
FUSE 5
FUSE 8
FUSE BLOCK (J/B) (UNDER LEFT
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IPDM E/R (INTELLIGENT POWER
K LINE
LT GRN WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
ORG/ WIRE
PNK NAVIGATION WIRE
PNK WIRE
PNK/BLU WIRE
STEERING ANGLE SENSOR (ON STEERING COLUMN)
TCM (TRANSMISSION CONTROL MODULE) (CVT) (LEFT SIDE OF ENGINE COMPT)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ INTELLIGENT KEY SYSTEM
W/ PNK NAVIGATION WIRE
W/O
W/O INTELLIGENT KEY SYSTEM
Go to component -> Computer data lines circuit -> BLU WIRE
Wiring diagram blu (14 of 69)
+G +B MOTOR FAN-RLY GND
2 1 3 2 PNK WIRE
38 44 ECT SENS SENS GND PNK WIRE
84 83 COMPUTER DATA LINES SYSTEM CAN-H CAN-L PNK WIRE
ALL TIMES
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN RELAY
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF CYLINDER HEAD)
FUSE 51
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK F
GND (SIG) CAN-H CAN-L
GRN WIRE
HOT AT
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY 1
LT GRN WIRE
LT GRN/BLK WIRE
M/T CVT
MOTOR MOTOR FAN-HIGH FAN-LOW
PNK WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> BLU WIRE
Wiring diagram blu (15 of 69)
72 33 36 34 PWR SPLY
95 84 83 GNDA-ASCDSW CAN-H CAN-L
ACCEL/RES SWITCH
ASCD STEERING SWITCH (IF EQUIPPED)
ASCDSW
BLK WIRE
BLU WIRE
BRK PEDAL POS SW
BRN WIRE
CANCEL SWITCH
CLUTCH PEDAL POS SW
CLUTCH PEDAL POSITION SWITCH (M/T) (ON CLUTCH
COAST/ SET SWITCH
COMPUTER DATA LINES SYSTEM PNK WIRE
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
FUSE 3
FUSE 30
FUSE 5
FUSE 8
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
M/T CVT, A/T SEDAN HATCHBACK 3 4
NCA WIRE
ON/OFF (MAIN) SWITCH
ORG/ WIRE
PEDAL BRACKET)
PNK 4 1 11 MOTOR (CLOSE) MOTOR (OPEN) GND WIRE
PNK WIRE
PPL
PPL (OR PNK) WIRE
RED WIRE
SENS GND
STOP LAMP SW
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
THROTTLE CONTROL MOTOR ELECTRIC THROTTLE CONTROL ACTUATOR (ON THROTTLE BODY)
THROTTLE POSITION SENSOR
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 2) -> BLU WIRE
Wiring diagram blu (16 of 69)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 49
GRY WIRE
HATCHBACK
HOT IN ON OR START
IGN
LT GRN/RED WIRE
O/P SPD SENS
OUTPUT SPEED SENSOR (ON TRANSAXLE)
PNK WIRE
PRI SPD SENS
PRIMARY SPEED SENSOR (CVT) (TOP OF TRANSAXLE)
PWR SPLY
RED WIRE
SEC SPD SENS
SECONDARY SPEED SENSOR (CVT) (RIGHT SIDE OF TRANSAXLE)
SEDAN LATE PRODUCTION SEDAN EARLY PRODUCTION, HATCHBACK
TRANSMISSION CONTROL MODULE (TCM) (LEFT SIDE OF ENGINE COMPT)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Cruise control circuit (2 of 2) -> BLU WIRE
Wiring diagram blu (17 of 69)
55 50 67 70 GND BAT (F/L)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONDENSER (LEFT "D" PILLAR)
FRONT AIR CONTROL
FUSE
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT DOOR MIRROR (W/ HEATED MIRRORS) DOOR MIRROR DEFOGGER
ORG/ WIRE
PPL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER INDICATOR
REAR WINDOW DEFOGGER RELAY (IN RELAY HOLDER ABOVE FUSE BLOCK (J/B))
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RIGHT DOOR MIRROR (W/ HEATED MIRRORS) DOOR MIRROR DEFOGGER
RR DEF RELAY OUT 38 39 40 10 IG SW CAN-H CAN-L RR DEF SW 39 40 15 PNK WIRE
W/ HEATED MIRRORS
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
YEL WIRE
Go to component -> Defoggers circuit -> BLU WIRE
Wiring diagram blu (18 of 69)
17 18 +B GND
84 83 CAN-H CAN-L PNK WIRE
ABS ACTUATOR, ELECTRIC UNIT (RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES (BEHIND LEFT SIDE OF DASH) SYSTEM
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
EPS CONTROL UNIT (ON STEERING COLUMN)
FUSE 3
FUSE 8
FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK J
GND(CKT)
GND(ILL)
GND(PWR)
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) FUSE 5
IGN
LEFT EPS MOTOR
LT GRN WIRE
ORG/ WIRE
PNK CAN-L WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT PS IND
TORQUE SENSOR
TSV TSS TSE (GND) TSM
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> BLU WIRE
Wiring diagram blu (19 of 69)
39 40 39 40 CAN-H CAN-L
70 57 67 BAT (F/L) BAT (FUSE) GND
84 83 CAN-H CAN-L
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM PNK WIRE
COMPUTER PNK DATA LINES SYSTEM WIRE
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK FUSE (J/B) (UNDER LEFT END OF DASH)
HOT IN ON OR START
IGN SW
IMMOB TOW WAY COMMUNICATION
LT GRN WIRE
NATS ANTENNA AMPLIFIER (RIGHT SIDE OF STEERING COLUMN)
ORG/ WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SECURITY IND
SECURITY IND OUTPUT IMMOB ONE WAY COMMUNICATION
W/O INTELLIGENT KEY SYSTEM W/ INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit -> BLU WIRE
Wiring diagram blu (20 of 69)
30 31 32 PNK WIRE
AIR FUEL RATIO (A/F) SENSOR 1 (ON EXHAUST MANIFOLD)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
ELECTRIC THROTTLE CONTROL ACTUATOR (ON THROTTLE BODY) THROTTLE CONTROL MOTOR
EVAP SOL VAL GND GND FUEL INJ 1
FUEL INJ 2 IGN SIG 4 IGN SIG 3 FUEL PMP RLY FUEL INJ 4 FUEL INJ 4 EVAP VNT VAL
FUEL INJ 3 FUEL INJ 2 FUEL INJ 1 SELF SHT OFF
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HATCHBACK
HEATED OXYGEN SENSOR 2 (ON EXHAUST SYSTEM, DOWNSTREAM OF THREE WAY CATALYST)
INTAKE AIR TEMPERATURE SENSOR
LT BLU WIRE
LT GRN WIRE
MASS AIR FLOW SENSOR (W/ INTAKE AIR
MOTOR OPEN MOT SPLY A/F HTR MOTOR CLOSE SENSOR 2 HTR
MTR RLY FUEL INJ 3 IGN SIG 1 IGN SIG 2
NCA WIRE
ORG/ WIRE
PNK OIL TEMP SNSR BATT SENS SENS GND SENS GND WIRE
PNK WIRE
PPL
PPL 10 11 12
RED WIRE
RED/WHT WIRE
SEDAN
SENS GND KNOCK SNSR COOLANT TEMP BATT TEMP SENS GND
TEMPERATURE SENSOR) (ON AIR CLEANER ASSEMBLY)
THROTTLE POSITION SENSOR
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 1.6l (1 of 5) -> BLU WIRE
