Nissan Note E12 (2012-2016) back door lock actuator relay (in relay holder Wiring diagrams
This page contains all the electrical diagrams for the component. back door lock actuator relay (in relay holder, in which he is found in the car Nissan Note E12 (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram back door lock actuator relay (in relay holder (1 of 2)
23 45 46 47 48 SECURITY IND DOOR SW (AS) DOOR SW (RR) DOOR SW (DR) DOOR SW (RL)
31 13 12 DOOR LOCK STATUS SW (DR) CENTRAL DOOR UNLOCK SW CENTRAL DOOR LOCK SW
40 39 PNK CAN-L CAN-H WIRE
49 55 LUGGAGE LAMP OUTPUT DR UNLOCK OUTPUT (RR, RL)
51 43 50 REQUEST SW (TRUNK) DOOR SW(AS) DOOR UNLOCK OUTPUT (BACK)
57 70 BATTERY (FUSE) BATTERY (F/L)
59 65 66 DOOR UNLOCK OUTPUT (AS) DOOR LOCK OUTPUT DOOR UNLOCK COMMON (DR)
63 56 INTERIOR ROOM LAMP OUTPUT BATT SAVER OUTPUT LIGHTS SYSTEM
67 61 60 GND RIGHT FLASHER OUTPUT LEFT FLASHER OUTPUT EXTERIOR LIGHTS SYSTEM PPL
BACK DOOR LOCK ACTUATOR RELAY (IN RELAY HOLDER
BACK DOOR REQUEST SWITCH
BACK DOOR SWITCH
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR (PARK POSITION SWITCH) (W/ CVT)
FUSE
FUSE FUSE (UNDER LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OUTSIDE KEY ANTENNA (REAR BUMPER) (BEHIND CENTER OF REAR BUMPER)
PNK 18 19 20 21 22 23 24 25 26 27 28 WIRE
PNK WIRE
PPL
PPL PNK WIRE
PPL PPL
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, with intelligent key unit (1 of 4) -> BACK DOOR LOCK ACTUATOR RELAY (IN RELAY HOLDER
