Nissan Note E12 (2012-2016) air con ind out Wiring diagram

AIR CON IND OUT BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLK/WHT WIRE BLOWER FAN SW BLOWER RELAY BLU WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DEFROST MODE SWITCH FAN SWITCH FR DEF SW FRONT AIR CONTROL FRONT BLOWER MOTOR FRONT BLOWER MOTOR RESISTOR (BOTTOM OF HVAC UNIT) FUSE 20 FUSE 21 FUSE 22 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) FUSIBLE LINK BOX (BATTERY) (ON BATTERY (+) TERMINAL) FUSIBLE LINK C GRN WIRE HOT AT ALL TIMES HOT IN ON LT BLU WIRE LT GRN WIRE OFF ON A/C SWITCH ORG/ WIRE PNK 3 4 WIRE PNK 4 2 WIRE PNK 40 39 27 26 40 39 27 26 CAN-L CAN-H AIR CON SW THERMO SW WIRE PPL REAR WINDOW DEFOGGER INDICATOR REAR WINDOW DEFOGGER SWITCH RED WIRE W/ INTELLIGENT KEY SYSTEM W/ A/C ON INDICATOR W/O INTELLIGENT KEY SYSTEM WHT WIRE YEL WIRE
