Nissan Note E12 (2012-2016) 83 84 pnk computer data lines system can-l can-h Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 PNK WIRE 1 2 3 A VCCI OIL PRESS GND A 39 40 23 CAN-H CAN-L SECURITY IND OUT PNK WIRE 58 59 48 47 DOOR SW (RL) DOOR SW (DR) 60 47 74 GND A OIL PRESS A VCCI 83 84 PNK COMPUTER DATA LINES SYSTEM CAN-L CAN-H WIRE ABS IND. AIR BAG IND BACK DOOR SWITCH BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE IND BRN WIRE BUZZER CAN L CAN-H CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM CRUISE IND (W/ ASCD) DISTRIBUTION MODULE ENGINE ROOM) (LEFT REAR OF ENGINE COMPT) DOOR IND DOOR SW (AS) ECM (ENGINE CONTROL MODULE) ENGINE OIL PRESSURE SENSOR (LOWER LEFT SIDE OF ENGINE BLOCK) FRONT FOG LAMP IND (IF EQUIPPED) FUEL LEVEL SENSOR UNIT, FUEL PUMP (TOP OF FUEL TANK) FUSE 3 FUSE 8 GRN WIRE GRY WIRE HIGH BEAM IND HOT AT ALL TIMES HOT IN ON OR ACC FUSE BLOCK (J/B) (UNDER LEFT FUSE 18 END OF DASH) HOT IN ON OR START IPDM E/R (INTELLIGENT POWER JOINT CONNECTOR KEY IND (W/ INTELLIGENT KEY SYSTEM) LEFT FRONT DOOR SWITCH (LEFT FRONT ``B" PILLAR) LEFT REAR DOOR SWITCH LEFT TURN IND LT BLU WIRE LT GRN WIRE MALFUNCTION IND LAMP (MIL) NAVIGATION, SOUND SYSTEMS O/D OFF (W/ CVT) OIL PRESSURE IND ORG/ WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY) PNK PNK PNK WIRE PNK WIRE PPL PPL PNK PPL WIRE PS IND PUSH ENGINE START IND (W/ INTELLIGENT KEY SYSTEM) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RIGHT TURN IND SEAT BELT IND SECURITY IND (W/ IMMOBILIZER) SLIP IND SPEEDOMETER STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TACHOMETER TAIL IND TIRE PRESSURE IND UNIFIED METER CONTROL UNIT VDC OFF IND W/ INTELLIGENT KEY SYSTEM W/O INTELLIGENT KEY SYSTEM WASHER IND (CANADA) WHT WIRE WIPER/WASHER SYSTEM YEL WIRE
