Nissan Note E12 (2012-2016) 38 44 ect sens sens gnd pnk Wiring diagrams

+G +B MOTOR FAN-RLY GND 2 1 3 2 PNK WIRE 38 44 ECT SENS SENS GND PNK WIRE 84 83 COMPUTER DATA LINES SYSTEM CAN-H CAN-L PNK WIRE ALL TIMES BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN HIGH RELAY COOLING FAN LOW RELAY COOLING FAN MOTOR (BEHIND RADIATOR) COOLING FAN RELAY ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (REAR OF CYLINDER HEAD) FUSE 51 FUSE, FUSIBLE LINK BOX FUSIBLE LINK F GND (SIG) CAN-H CAN-L GRN WIRE HOT AT HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY 1 LT GRN WIRE LT GRN/BLK WIRE M/T CVT MOTOR MOTOR FAN-HIGH FAN-LOW PNK WIRE YEL WIRE

+G +B 2 1 3 2 PNK WIRE 3 2 1 PPL 38 44 ECT SENS SENS GND PNK WIRE 98 85 101 84 83 GND-PDPRESS PDPRESS PPL A/C COMP MOTOR GND FAN-RLY (SIG) GND A/C COMPRESSOR (LEFT FRONT OF ENGINE) A/C RELAY ALL TIMES BLK WIRE BLU WIRE BRN WIRE CAN-H- CAN-L- COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CAN-H CAN-L PNK WIRE COOLING FAN HIGH RELAY COOLING FAN LOW RELAY COOLING FAN RELAY (LEFT SIDE OF ENGINE COMPT) COOLING M/T FAN MOTOR CVT (BEHIND RADIATOR) ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (REAR OF CYLINDER HEAD) ENGINE ROOM) (LEFT REAR OF ENGINE COMPT) FUSE 42 FUSE 51 FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE HOT AT HOT AT ALL TIMES HOT IN ON OR START HVAC UNIT) IGNITION RELAY 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE LT GRN WIRE LT GRN/BLK WIRE M/T CVT MOTOR FAN-HIGH MOTOR FAN-LOW ORG/ WIRE PNK WIRE PPL REFRIGERANT PRESSURE SENSOR (ON A/C LIQUID TANK) THERMO CONTROL AMP (BOTTOM OF WHT WIRE YEL WIRE
