Car Wiring Diagrams for Charging circuit for Nissan Murano Z51 facelift (2010-2012)

ALTERNATOR BATTERY BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE CAN-H CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) FUSE (J/B) (LEFT END OF DASH) FUSE BLOCK FUSIBLE LINK A FUSIBLE LINK HOLDER (AT POSITIVE BATTERY TERMINAL) HOT IN ON OR START LT BLU WIRE NCA WIRE ORG/ WIRE PNK CAN-L WIRE PNK WIRE STARTER MOTOR WHT WIRE YEL/BLK WIRE
