Nissan Murano Z51 facelift (2010-2012) trans range trans trans range range range Wiring diagram
This page shows the only wiring diagram for the component.trans range trans trans range range range, which is found in the car Nissan Murano Z51 facelift (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans range trans trans range range range (1 of 1)
BACK UP LAMP RLY TRANS
BACKUP LAMP RELAY (LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN (-) CAN (+)
COMPUTER DATA LINES SYSTEM
CVT UNIT
FUSE 4
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN ON OR START
LEFT BACKUP LAMP
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT BACKUP LAMP
TRANS RANGE TRANS TRANS RANGE RANGE RANGE
TRANSMISSION CONTROL MODULE (TCM) (ON TRANSMISSION) TRANS RANGE MON
TRANSMISSION RANGE SWITCH
WHT WIRE
Go to component -> Backup lamps circuit -> TRANS RANGE TRANS TRANS RANGE RANGE RANGE
