Electronic power steering circuit for Nissan Murano Z51 facelift 2 (2011-2015)

1 2 3 4 5 6 7 8 9 10 11 12 EPS SOL+ BLK WIRE BLU WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM ENG SPD ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) EPS SOL GND FUSE FUSE BLOCK (J/B) (LEFT END OF DASH) GRN WIRE GRY WIRE HOT IN ON OR START IGN LT GRN WIRE OUTPUT SIGNAL PNK WIRE POWER STEERING CONTROL UNIT (RIGHT CENTER OF DASH) POWER STEERING SOLENOID VALVE (LEFT FRONT OF ENGINE COMPT) PPL PPL ENG TACHO RIGHT END OF DASH) VEH SPD YEL WIRE
