Nissan Murano Z50 (2002-2008) Shift interlock circuit, with intelligent key unit

1 2 BAT (+) DETENT SW (KEY) 3 4 5 6 7 DETENT SW (SHIFT) BRAKE SW VSP SIGNAL IGN SW SHIFT LOCK SOL OUTPUT 8 9 GND KEY LOCK SOL OUTPUT (LOCK) 8 P/R BLK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE CVT DEVICE DETENT SWITCH (KEY) DETENT SWITCH (SHIFT) DIODE'S (BEHIND UPPER LEFT SIDE OF DASH) FUSE 12 FUSE 20 FUSE BLOCK (J/B) (BELOW LEFT SIDE OF DASH) FUSE 22 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START KEY LOCK SOL + KEY LOCK SOL OUTPUT (UNLOCK) KEY SWITCH, IGNITION KNOB SWITCH ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE SHIFT LOCK CONTROL UNIT (BEHIND LEFT SIDE OF DASH) SHIFT LOCK SOLENOID STOP LAMP SWITCH (ABOVE BAKE PEDAL, ON BRACKET) UNIFIED METER, A/C AMPLIFIER (BEHIND LOWER CENTER OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
