Nissan Murano Z50 (2002-2008) warning gnd led l cathode led r cathode wiring diagram
This page shows the only wiring diagram for the component.warning gnd led l cathode led r cathode, which is found in the car Nissan Murano Z50 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
warning gnd led l cathode led r cathode wiring diagram (1 of 1)
B+ B-
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN L
FUSE 71
FUSE 78
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IGN
LEFT FRONT COMBINATION LAMP
LEFT REAR COMBINATION LAMP
LEFT TURN SIGNAL
NCA WIRE
PARKING
REAR COMBINATION LAMP CONTROL UNIT (IN REAR OF VEHICLE)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TURN SIGNAL
SIDE MARKER
SIDE MARKER LAMP
TAIL LAMP RELAY
TAIL/L RLY GND (PWR) GND (SIG) CAN -H
TURN/ STOP/ TAIL LAMP
WARNING GND LED L CATHODE LED R CATHODE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> WARNING GND LED L CATHODE LED R CATHODE
