Nissan Murano Z50 (2002-2008) memory switch-2 memory switch-1 Wiring diagram
This page shows the only wiring diagram for the component.memory switch-2 memory switch-1, which is found in the car Nissan Murano Z50 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory switch-2 memory switch-1 (1 of 1)
33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 POWER SUPPLY (SENS) BAT
38 11 37 39 40 IGN
55 52 BAT GND
BAT GND (SIG) GND (SENS)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/YEL WIRE
CIRCUIT BREAKER (LEFT SIDE OF DASH, NEAR FUSE BLOCK (J/B))
COMPUTER DATA LINES SYSTEM
DETENTION SWITCH CVT DEVICE
DIODE (W/ INTELLIGENT KEY)
DOOR SW (DR)
FRONT DOOR LOCK ASSEMBLY (DRIVER SIDE DOOR SWITCH)
FUSE 1
FUSE 21 FUSE 22 (BELOW LEFT SIDE OF DASH)
FUSE 6
FUSE BLOCK (J/B)
GND POWER
GRN WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
KEY SW CAN-H CAN-L
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MEMORY INDICATOR 1
MEMORY INDICATOR 2
MEMORY SWITCH-2 MEMORY SWITCH-1
MIRROR MOTOR (RH COM) MIRROR MTR (LH VERT) MIRROR MTR (LH HORIZ)
MIRROR MTR (RH VERT) MIRROR MTR (RH HORIZ) MIRROR MTR (LH COM)
ORG/ WIRE
PEDAL MOTOR (FR)
PEDAL MOTOR (RR)
PEDAL SENSOR
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
SEAT MEMORY SWITCH
SET SW
SET SWITCH
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Memory systems circuit (1 of 3) -> MEMORY SWITCH-2 MEMORY SWITCH-1
