Nissan Maxima A36 (2015-2024) security ind left turn ind Wiring diagram
This page shows the only wiring diagram for the component.security ind left turn ind, which is found in the car Nissan Maxima A36 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram security ind left turn ind (1 of 1)
ABS IND.
AEB OFF IND (W/ ICC)
AIR BAG IND
AUTO ANTI-DAZZLING INSIDE MIRROR
BELT IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRN WIRE
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EPS IND
FOG LIGHT IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT, FUEL PUMP (FUEL LEVEL SENSOR)
FUSE 13
FUSE 21
FUSE 3
FUSE 30
FUSE 31
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HIGH BEAM (BLUE) IND
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
LIGHT (GREEN) IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
MASTER (YELLOW) IND
OIL IND
PARKING BRAKE SWITCH
PNK WIRE
POWER TOPS SYSTEM
PPL
RED WIRE
RIGHT END OF DASH)
RIGHT TURN IND
SECURITY IND LEFT TURN IND
SLIP IND
SOUND, NAVIGATION SYSTEMS
SPEEDOMETER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAN WIRE
TIRE PRESSURE IND
TRANSMISSIONS SYSTEM
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VDC OFF IND
WATER TEMP GAUGE
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> SECURITY IND LEFT TURN IND
