Nissan Maxima A35 (2008-2014) right rear step lamp left front step lamp Wiring diagram
This page shows the only wiring diagram for the component.right rear step lamp left front step lamp, which is found in the car Nissan Maxima A35 (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear step lamp left front step lamp (1 of 1)
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
CPU UNLOCK
FULL FULL STROKE STROKE
LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) (REAR OF DRIVER'S DOOR)
LEFT FRONT KICK PLATE LAMP (PRE-WIRING)
LEFT REAR STEP LAMP
LEFT VANITY MIRROR LAMP
LOCK
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
OFF
ORG/ WIRE
PNK WIRE
PNK/ (LEFT CENTER OF DASH) WIRE
PNK/WHT WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT KICK PLATE LAMP (PRE-WIRING)
RIGHT FRONT STEP LAMP
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT REAR STEP LAMP LEFT FRONT STEP LAMP
RIGHT VANITY MIRROR LAMP
TRUNK ROOM LAMP
UNLOCK
UNLOCK SWITCH LOCK SWITCH
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT REAR STEP LAMP LEFT FRONT STEP LAMP
