Car Wiring Diagrams for Charging circuit for Nissan Maxima A34 (2003-2008)

BATTERY BLK WIRE BRN WIRE CHARGE INDICATOR COMBINATION METER FUSE FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE FUSE LINK BOX (AT LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK A FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT) GENERATOR GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON OR START NCA WIRE ORG/ WIRE RED WIRE STARTING CIRCUIT UNIFIED METER CONTROL UNIT YEL WIRE
