Nissan Maxima A34 (2003-2008) Shift interlock circuit

1 2 3 4 5 6 7 8 9 10 BAT DETENT SW A/T DEVICE (UNDER CENTER CONSOLE) BLK WIRE BLK/RED WIRE BRN WIRE BRN/YEL WIRE DETENT SWITCH (KEY) FUSE 12 FUSE 19 FUSE 21 FUSE 20 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START KEY LOCK SOLENOID KEY SWITCH, KEY LOCK SOLENOID (ON STEERING COLUMN) NCA WIRE PNK/BLU WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE SHIFT LOCK CONTROL UNIT (NEAR FUSE BLOCK (J/B)) SHIFT LOCK SOLENOID STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH) WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
