Car Wiring Diagrams for Defoggers circuit for Nissan Maxima A34 (2003-2008)

+B RR DEF RELAY +IG 22 29 30 IGN GND GND 38 56 RR DEF ON RR DEF F/B 38 9 39 40 IGN RR DEF SW CAN-H CAN-L 55 52 BAT GND BLK WIRE BLU WIRE BLU/BLK WIRE BODY CONTROL MODULE (BCM) (NEAR FUSE BLOCK (J/B)) CAN-L CAN-H COMPUTER DATA LINES SYSTEM CONDENSER (AT LEFT "C" PILLAR) FUSE 1 FUSE 12 FUSE 34 FUSE 37 FUSE 32 FUSE 8 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK F GND (SIGNAL) GND POWER GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT) LEFT DOOR MIRROR DOOR MIRROR DEFOGGER PNK 11 1 CAN-L CAN-H WIRE PNK WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY (AT LEFT KICK PANEL) RED/WHT WIRE RIGHT DOOR MIRROR (DOOR MIRROR DEFOGGER) UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH) WHT WIRE WHT/BLK WIRE
