Nissan Maxima A34 (2003-2008) right license plate lamp left cornering lamp Wiring diagram
This page shows the only wiring diagram for the component.right license plate lamp left cornering lamp, which is found in the car Nissan Maxima A34 (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right license plate lamp left cornering lamp (1 of 1)
1 2 3 4 5 PNK WIRE
11 1 9 19 PNK CAN-L CAN-H TX (COMB METER) RX (COMB METER) WIRE
29 30 21 22 GND GND BATT IGN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/YEL WIRE
BUZZER 23 10 11 12
COMBINATION METER
FUSE 1
FUSE 12
FUSE 14
FUSE 19
FUSE 20
FUSE 21
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LEFT FRONT COMBINATION LAMP
LEFT LICENSE PLATE LAMP
LEFT TURN IND
ORG/ WIRE
ORG/BLU WIRE
PNK/BLU WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CORNERING LAMP
RIGHT LICENSE PLATE LAMP LEFT CORNERING LAMP
RIGHT TURN IND
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TURN PARK
UNIFIED METER CONTROL UNIT
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT LICENSE PLATE LAMP LEFT CORNERING LAMP
