Nissan Maxima A34 (2003-2008) heated steering switch Wiring diagram
This page shows the only wiring diagram for the component.heated steering switch, which is found in the car Nissan Maxima A34 (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated steering switch (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
COMBINATION SWITCH (HEATED STEERING)
FUSE 12
FUSE 30
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPARTMENT)
GRN WIRE
HEATED STEERING RELAY
HEATED STEERING SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM
RED/BLU WIRE
RED/YEL WIRE
Go to component -> Heated steering wheel circuit -> HEATED STEERING SWITCH
