Nissan Maxima A34 (2003-2008) 1 2 3 4 5 6 7 8 9 10 bat detent sw Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 10 bat detent sw, which is found in the car Nissan Maxima A34 (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 bat detent sw (1 of 1)
1 2 3 4 5 6 7 8 9 10 BAT DETENT SW
A/T DEVICE (UNDER CENTER CONSOLE)
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/YEL WIRE
DETENT SWITCH (KEY)
FUSE 12
FUSE 19 FUSE 21
FUSE 20
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
KEY LOCK SOLENOID
KEY SWITCH, KEY LOCK SOLENOID (ON STEERING COLUMN)
NCA WIRE
PNK/BLU WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SHIFT LOCK CONTROL UNIT (NEAR FUSE BLOCK (J/B))
SHIFT LOCK SOLENOID
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Shift interlock circuit -> 1 2 3 4 5 6 7 8 9 10 BAT DETENT SW
