Nissan Maxima A33 (1999-2006) stop turn Wiring diagram
This page shows the only wiring diagram for the component.stop turn, which is found in the car Nissan Maxima A33 (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop turn (1 of 1)
45 46 FLASHER OUT (LEFT) FLASHER OUT (RIGHT)
49 52 55 42 GND GND BAT (F/L) BAT (FUSE)
6 14 DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BODY CONTROL MODULE (BCM) (NEAR FUSE BLOCK (J/B))
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 21
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK F
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LEFT REAR COMBINATION LAMP
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP PARK TURN
RIGHT REAR COMBINATION LAMP
SIDE MARKER TAIL
SIDE MARKER TAIL/ STOP
STOP
STOP TURN
TAIL
TAIL STOP
TURN
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> STOP TURN
