Nissan Maxima A33 (1999-2006) left cornering Wiring diagram
This page shows the only wiring diagram for the component.left cornering, which is found in the car Nissan Maxima A33 (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left cornering (1 of 1)
BLK WIRE
BLU WIRE
CIGARETTE LIGHTER
FROM ACCESSORY RELAY (DIAGRAM 2 OF 3)
FROM FUSE 41 (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK C (DIAGRAM 2 OF 3)
FRONT POWER SOCKET
FUSE 17
FUSE 18
FUSE 22
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT)
LAMP RELAY
LEFT CORNERING
LT BLU WIRE
ORG/ WIRE
REAR POWER SOCKET
REAR POWER SOCKET RELAY (W/ REAR POWER SOCKET)
RIGHT CORNERING LAMP RELAY
SOUND SYSTEMS
SOUND, POWER WINDOWS SYSTEMS
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> LEFT CORNERING
