Nissan Maxima A33 (1999-2006) illum illum Wiring diagrams
This page contains all the electrical diagrams for the component. illum illum, in which he is found in the car Nissan Maxima A33 (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram illum illum (1 of 2)
BLK WIRE
BLU WIRE
FUSE 29
FUSE 41
FUSE BLOCK (J/B) (AT LEFT FRONT OF ENGINE COMPT) FUSE 12
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEATED SEAT RELAY (NEAR FUSE BLOCK (J/B))
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM ILLUM
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS
IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT)
LEFT FRONT HEATED SEAT SWITCH
LEFT FRONT SEAT HEATER (UNDER LEFT FRONT SEAT)
LOW HIGH HIGH OFF OFF
LOW HIGH OFF
LOW HIGH OFF OFF
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT HEATED SEAT SWITCH
RIGHT FRONT SEAT HEATER (UNDER RIGHT FRONT SEAT)
SYSTEM
TAIL LAMP RELAY
Go to component -> Heated seats circuit, without rear heated seats -> ILLUM ILLUM
Wiring diagram illum illum (2 of 2)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
FUSE 24
FUSE 29
FUSE 41
FUSE BLOCK (J/B) (AT LEFT FRONT OF ENGINE COMPT) FUSE 12
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEATED SEAT RELAY (NEAR FUSE BLOCK (J/B))
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM ILLUM
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS
IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT)
LEFT FRONT HEATED SEAT SWITCH
LEFT FRONT SEAT HEATER (UNDER LEFT FRONT SEAT)
LOW HIGH OFF
LOW HIGH OFF OFF
LT BLU WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT HEATED SEAT SWITCH
RIGHT FRONT SEAT HEATER (UNDER RIGHT FRONT SEAT)
SYSTEM
TAIL LAMP RELAY
Go to component -> Heated seats circuit, with rear heated seats (1 of 2) -> ILLUM ILLUM
