Nissan Maxima A33 (1999-2006) horn relay can-h can-l Wiring diagram

+IG 49 52 42 55 GND (SIGNAL) GND (POWER) BAT (FUSE) BAT (F/L) 57 62 63 TRUNK STATUS SW DOOR SW (DR) DOOR SW (RL) BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) 6 14 FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) (AT REAR OF FUSE 21 FUSE 34 FUSE 38 FUSE 45 FUSE 40 FUSE 36 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE 19 FUSE 6 FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT) FUSE 25 FUSIBLE LINK F GND (SIGNAL) GND POWER GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE H/LP HI H/LP LO HEADLAMP HIGH RELAY HEADLAMP LOW RELAY HEADLIGHTS SYSTEM HORN (HIGH) (AT RIGHT FRONT OF ENGINE COMPT) HORN (LOW) (AT LEFT FRONT OF ENGINE COMPT) HORN RELAY (IN FUSE, FUSIBLE LINK BOX) HORN RELAY CAN-H CAN-L HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGNITION RELAY LEFT FRONT DOOR SWITCH (AT FRONT OF LEFT FRONT DOOR SILL) LEFT REAR DOOR SWITCH (AT REAR OF LEFT REAR DOOR SILL) LOCK SWITCH FULL STROKE LT BLU WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH POWER WINDOW SERIAL LINK PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH (AT FRONT OF RIGHT FRONT DOOR SILL) RIGHT FRONT POWER WINDOW SWITCH POWER WINDOW SERIAL LINK SECURITY INDICATOR LAMP UNLOCK LOCK UNLOCK SWITCH FULL STROKE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE
