Nissan Maxima A33 (1999-2006) ftrps phase rh ta Wiring diagram

AVCC PDPRES BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE C-IVC (L) C-IVC (R) PS PRES POS PHASE LH CAMSHAFT POSITION SENSOR (PHASE) (BANK 1) (REAR OF RIGHT CYL HEAD) COMBINATION METER CONDENSER 2 (NEAR TOP OF ENGINE) CRANKSHAFT POSITION SENSOR (POS) (LEFT REAR OF ENGINE) EGR VOLUME CONTROL VALVE (LEFT REAR OF ENGINE COMPT) EGRTS ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) EVAP FTRPS PHASE RH TA FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 6 FUSE 1 FUSE 14 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HOT IN ON OR START INJ 5 INJ 3 INJ 1 INJ 6 INJ 4 INJ 2 KNOCK SENSOR (ON TOP OF CYLINDER BLOCK) LT GRN/BLK WIRE LT GRN/RED WIRE MALFUNCTION INDICATOR LAMP NCA WIRE ORG/ WIRE ORG/BLU WIRE PNK WIRE PNK/BLK WIRE QA+ RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REFRIGERANT PRESSURE SENSOR (ON A/C LIQUID TANK) UNIFIED METER CONTROL UNIT V MOT VIAS VIO WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL/BLK WIRE
