Nissan Maxima A33 (1999-2006) door lock-unlock sw Wiring diagram
This page shows the only wiring diagram for the component.door lock-unlock sw, which is found in the car Nissan Maxima A33 (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door lock-unlock sw (1 of 1)
41 42 47 48 49 52 BAT SAVER OUT BAT (FUSE) STEP LAMP OUT ROOM LAMP OUT GND GND
55 57 62 63 BAT (F/L) T/L OP SW DOOR SW (DR) DOOR SW (RL)
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (NEAR FUSE BLOCK (J/B))
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIODE 5 (AT LEFT FRONT OF LUGGAGE COMPT)
DOOR LOCK-UNLOCK SW
FULL STROKE LOCK SW FULL STROKE UNLOCK SW
FUSE 21
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE 1
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK F
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
KEY SWITCH, KEY LOCK SOLENOID (ON STEERING COLUMN)
LEFT FRONT DOOR KEY CYLINDER SWITCH (AT REAR OF LEFT FRONT DOOR)
LEFT FRONT DOOR SWITCH (AT FRONT OF LEFT FRONT DOOR SILL)
LEFT FRONT STEP LAMP
LEFT REAR DOOR SWITCH (AT REAR OF LEFT REAR DOOR SILL)
LEFT REAR STEP LAMP
LOCK
LT BLU WIRE
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT STEP LAMP
RIGHT REAR DOOR SWITCH (AT REAR OF RIGHT REAR DOOR SILL)
RIGHT REAR STEP LAMP
TRUNK LAMP SWITCH, TRUNK RELEASE SOLENOID (AT REAR CENTER OF LUGGAGE LID)
TRUNK ROOM LAMP
UNLOCK
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> DOOR LOCK-UNLOCK SW
