Nissan Maxima A33 (1999-2006) bus+ bus shield bus- Wiring diagram

AUDIO UNIT AV SWITCH BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BUS - BUS GND BUS+ BUS SHIELD BUS- COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DCU-DSP DCU-DSP DSP SHIELD DSP-DCU AUDIO SHIELD DCU-AUDIO SYNC GND AUDIO-DCU RGB SYNC DISPLAY CONTROL UNIT (BEHIND CENTER OF DASH) DISPLAY UNIT DOWN UP DSP-DCU FRSP LH (+) GRN WIRE GRN/WHT WIRE HP RGB SYNC IGN ILL ILL CONT INV GND INV VCC LT GRN WIRE NCA WIRE OFF ON OFF PNK WIRE PNK/BLU WIRE POWER SWITCH MODE SWITCH PPL PPL 6 7 8 9 10 11 12 13 PPL BUS (+) BUS SHIELD BUS (-) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RGB GND RGB SYNC SEEK SWITCH SHIELD SIGN GND SIGN VCC SOUND SYSTEMS SPEED STEERING WHEEL AUDIO CONTROL SWITCHES STRG SW A STRG SW C SW B STRG SYNC GND VOICE VOLUME SWITCH WHT WIRE YEL WIRE
